| Technical specification |
|---|
| Measurement | Default Spec Value4 Terminal Kelvin/Thomson principle eliminates error due to lead resistance. Open circuit measurement voltage approx. 5V dc. |
| Display | 15mm LCD 4,000 count with automatic decimal point and polarity indication |
| Ranges | 6 Ranges with automatic or manual selection |
| Auto Zero | Permits the automatic zero of amplifiers and external circuits eliminating errors due to thermal emf. |
| Calibration | Digital |
| Battery | 5 AA size manganese Alkaline supplied with unit. Rechargeable battery pack option includes 5 AA size Ni/Mhd, housed in removable cassette plus docking station and charger. Automatic Power OFF ensures maximum battery life |
| Temperature Compensation | The model 4002 also includes temperature compensation which references the measurement to an ambient temperature of 20 Deg.C. Coefficients for copper and aluminium are pre programmed and a user coefficient facility enables coefficients for any material to be entered. |
| Temperature Measurement | The Model 4002 also include temperature measurement over the range -50…+800 Deg C. Using a Pt100 temperature probe which may be ordered as an option. |
| Terminals | 4mm safety sockets |
| Working Temperature | 0…40°C rel. humidity 80% max. non-condensing |
| Storage Temperature | -20 … +50°C. |
| Charger Mains Supply | 100/120/220/240 Volts +10% -13%. 47 … 63Hz. 20VA |
| Safety | EN61010-1 EMC – EN61326 |
| Dimensions | 215 x 130 x55mm (W H D) |
| Weight | 0.8kg |
| Accessories | Supplied complete batteries, measuring leads with Kelvin Clips, handbook, and calibration certificate |
